步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

V

A

W

mH

Kg-cm

g-cm2

Kg

mm

39BYG9004

6

0.6

10

15

1.2

4

19.5

0.16

26

39BYG9104

4

0.5

8

9.5

0.8

4

12

0.11

20

39BYG9403

12

0.4

30

60

1.6

4

25

0.2

35

39BYG9703

9

0.6

15

26

2.2

4

43

0.28

46
